How to Choose a DC Electric Vehicle Charger?
Key considerations to ensure it meets your requirements.
- Charging Speed: Determine desired charging time based on power output.
- Charging Connector: Ensure compatibility with your EV's port, such as CHAdeMO, CCS, or combined systems.
- Safety Performance: Look for over-current, over-voltage, over-heat, and other protections.
- Installation: DC chargers require stronger power infrastructure than AC ones; check if your site (home, factory, commercial center, public station) supports it.
- User Experience: Opt for intuitive touch screens, menu interfaces, and mobile app integration for control, monitoring, and wireless updates.
DC Charger Series
20kW / 30kW / 40kW
20kW / 30kW / 40kW
Comprehensive Multi-Layer Protection
Each POWERIS product is built on a foundation of reliability and precision engineering, ensuring every charge remains stable and secure.
Our system integrates intelligent monitoring, real-time fault prevention, and smart temperature balance to provide a worry-free charging experience — always efficient, always safe.
Designed for the future of energy, POWERIS ensures safety, efficiency, and endurance are seamlessly unified.
Fast DC Charger Series Specifications
High-performance DC fast charger designed for intelligent and reliable operation.
| Model | 20kW | 30kW | 40kW |
|---|---|---|---|
| Input connection | 3-Phase (3P+N+PE) | ||
| Voltage input | 400Vac ±10% | ||
| THDi | ≤5% | ||
| Frequency | 50Hz or 60Hz | ||
| Power factor | ≥0.98 | ||
| Output voltage | 150Vdc–1000Vdc | ||
| Maximum output current | 62.5A | 94A | 125A |
| Rated power | 20kW | 30kW | 40kW |
| LCD monitor | 7"/10" color touch screen (optional) | ||
| User authentication | RFID (ISO/IEC14443) / APP / Credit card customization | ||
| LED indicator light | Green / Blue / Red (optional) | ||
| Charger connector | CCS2 (CCS1 / CHAdeMO optional) | ||
| Number of charging ports | 1 or 2 | ||
| Energy metering | DC ammeter with a measurement error of ±0.5% | ||
| Communication | Ethernet (4G optional) | ||
| Charging protocol | ISO 15118, DIN 70121 | ||
| Backend protocol | OCPP 1.6J (OCPP 2.x) | ||
| Residual current device | YES | ||
| Internal fuse | YES | ||
| Electrical protection | Charging gun temperature detection, overload protection, overvoltage protection, undervoltage protection, short circuit protection, grounding protection, overtemperature protection, insulation monitoring, reverse polarity protection, lightning protection, emergency stop protection, and leakage protection. | ||
| Working temperature | -30°C ~ +50°C | ||
| Storage temperature | -40°C ~ +75°C | ||
| Working humidity | Max. 93% relative humidity, non-condensing | ||
| Working height | ≤2000m | ||
| IP / IK rating | IP55, IK10 | ||
| Cooling method | Fan cooling | ||
| Product dimension | Wall-mounted: 600×370×800mm (W×D×H) | Column-mounted: 600×470×1600mm (W×D×H) | ||
| Charging cable length | 5m (Customizable) | ||
| Installation method | Standalone (Wall-mounted / Column-mounted) | ||
| Standards | IEC62196-1, IEC62196-3, IEC61851-1, IEC61851-23, IEC61851-24 | ||
| Product certification | CE | ||
